Specifications
| DC Voltage | 200mV/2V/20V/200V/1000V |
| DC Voltage - Accuracy | ±(0.1%+8) |
| AC Voltage | 2V/20V/200V/1000V |
| AC Voltage - Accuracy | ±(0.8%+40) |
| DC current | 200μA/2000μA/20mA/200mA/10A |
| DC current - Accuracy | ±(0.2%+20) |
| AC current | 200μA/2000μA/20mA/200mA/10A |
| AC current - Accuracy | ±(1.0%+15) |
| Resistance | 200Ω/2KΩ/20KΩ/200KΩ/2MΩ/20MΩ |
| Resistance - Accuracy | ±(0.5%+20) |
| capacitor | 20nF/200nF/2μF/20μF/200μF/2mF/20mF |
| Capacitance - Accuracy | ±(1.5%+20) |
| Frequency | 20Hz~200MHz |
| Frequency - Accuracy | ±(0.1%+15) |
| maximum display | 19999 |
| automatic range | Yes. |
| True RMS | Yes. |
| frequency response | 100KHz |
| duty cycle | (5Hz-2kHz)10~90% |
| Diode test | Yes. |
| Automatic shutdown | Yes. |
| on-off beep | Yes. |
| Low Voltage display | Yes. |
| number hold | Yes. |
| Relative measurement | Yes. |
| Max/MIN Minimum | Yes. |
| Interface | USB |
| LCD backlight | LCD dual backlight |
| analog strip | Yes. |
| full symbol display | Yes. |
| function settings | Yes. |
| Impedance | DC 200mV: Around 2.5GΩ，All Other Range：10MΩ |
| Current measurement dislocation alarm | Yes. |
| Voltage current | AC+DC |
| Power Supply | 9V Battery (6F22) |
| Display size | 73*50mm |
| Weight | 384g |
| Dimension | 200*93*40mm |
Packing list
Whole machine X1, watch pen X1, cloth bag X1, battery X1, crocodile clip X1, software CD X1, USB data cable X1, test short pen X1, point temperature sensor X1, Power conversion socket X1, load socket X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16435/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
