Specifications
| DC Voltage | 400mV/4V/40V/400V/1000V |
| DC Voltage - Accuracy | ±(0.025%+5) |
| AC Voltage | 4V/40V/400V/1000V |
| AC Voltage - Accuracy | ±(0.4%+30) |
| DC current | 400μA/4000μA/40mA/400mA/10A |
| DC current - Accuracy | ±(0.1%+15) |
| AC current | 400μA/4000μA/40mA/400mA/10A |
| AC current - Accuracy | ±(0.7%+15) |
| Resistance | 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ |
| Resistance - Accuracy | ±(0.3%+8) |
| capacitor | 40nF/400nF/4μF/40μF/400μF/4mF/40mF |
| Capacitance - Accuracy | ±(1%+20) |
| temperature | -40~1000℃ |
| Temperature - Accuracy | ±(1%+30) |
| Frequency | 40Hz~400MHz |
| Frequency - Accuracy | ±(0.01%+8) |
| Power | 2500W |
| maximum display | 39999 |
| automatic range | Yes. |
| True RMS | Yes. |
| frequency response | 100KHz |
| duty cycle | (5Hz-2kHz) ±(1%+30) |
| Diode test | Yes. |
| Automatic shutdown | Yes. |
| on-off beep | Yes. |
| Low Voltage display | Yes. |
| number hold | Yes. |
| Relative measurement | Yes. |
| Max/MIN Minimum | Yes. |
| Data storage | 100 |
| Interface | USB |
| LCD backlight | LCD dual backlight |
| analog strip | Yes. |
| full symbol display | Yes. |
| function settings | Yes. |
| Impedance | DC 400mV: about 2.5GΩ, other gears: 10MΩ |
| 10A fuse | Yes. |
| Current measurement dislocation alarm | Yes. |
| Voltage current | AC+DC |
| Power Supply | 9V Battery (6F22) |
| Display size | 73*50mm |
| Weight | 384g |
| Dimension | 200*93*40mm |
Packing list
UT71E-watch pen X1, cloth bag X1, battery X1, alligator clip X1, software CD X1, USB data cable X1, test short pen X1, point temperature sensor X1, Power conversion socket X1, load socket X1, color box X1, manual X1, warranty card X1
After-sales instructions
Warranty days: 365 days
