Specifications
| type | Slight oil silent piston machine |
| compression method | reciprocating |
| exhaust pressure | 0.8Mpa |
| Displacement | 670L/min |
| Body model | VA-100 |
| Bore × number of bars | Φ100mm*2 |
| Rotation speed | 950rpm |
| Air interface | 3/4'’ |
| Dimension | 960*830*1165mm |
| Weight | 310Kg |
| Input Power | 5.5kW |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
