FUSHENG FuSheng VW-50 Completely oil-free piston machine 420L/4kW
VW-50
FuSheng VW-50 Completely oil-free piston machineSPEC
FuSheng VW-50 Completely oil-free piston machineDetails
FuSheng VW-50 Completely oil-free piston machinePacking list
- SKU
- NB016553
- type
- Completely oil-free piston machine
- compression method
- reciprocating
- exhaust pressure
- 0.8Mpa
- Displacement
- 420L/min
- Gas tank Volume
- 114L
- Rotation speed
- 700rpm
- Air interface
- 1/2'’
- Dimension
- 1334*500*975mm
- Weight
- 222Kg
- Input Power
- 4.0kW
 | Valve Effective strip valves, all made of high-corrosion resistant stainless steel; Use high-temperature resistant materials to make lift limits; Effectively reduce the noise of the unit and improve the life of the valve group; Ensure continuous operation of the unit. |
 | piston Cast aluminum material is used, which has good anti-rust, anti-corrosion and thermal conductivity. |
 | Piston rings, guide rings It is made of special self-lubricating materials and precision machining; It has high wear resistance and temperature resistance; The stainless steel elastic ring structure is added to improve the sealing effect of the unit and the life of long-term continuous use. |
 | cylinder After the high-purity composition is cast, the precision machining unit grinds after processing, and then the surface is coated with self-lubricating materials by a special method. |
 | Connecting rod It is made of special aluminum alloy materials with high corrosion resistance and high strength, and is made of precision machining, boring and rolling by special machine tools after die-casting; Ensure that the compressor runs continuously more smoothly. |
 | bearing High-precision sealed grease bearings: the bearing grease is made of high-temperature resistant grease; Ensure long life and continuous operation of bearings. |
 | Crankcase ventilation The ventilation system is added on both sides of the crankcase to effectively reduce the temperature of the unit bearing during operation, improve the life of the unit bearing and control the temperature of continuous operation. |
