Specifications
| Measurement principle | Magnetic Induction + eddy Current |
| Measurement range | 0~1500μm |
| margin of error | ±1~3%/±2.5μm |
| Resolution | 0.1μm|1μm |
| Minimum measurement surface | F: 4mm；N: 6mm |
| Minimum radius of curvature | Depending on the probe selected |
| probe | Split |
| Calibrated Certificate | Yes. |
| Calibrated mode | Factory calibrated, two point calibrated, zero point calibrated, single point calibrated, zero point offset, preset calibrated, Automatic calibration |
| Unit display | μm/mils |
| statistical function | Number of readings, average value, standard deviation, minimum limit, maximum limit, coefficient of variation |
| Interface | USB、Bluetooth |
| Data storage | 150000 Measured values |
| Power Supply | 2 AA batteries, rechargeable batteries can also be used |
| Standards | AS 2331.1.4, AS 3894.3-B, AS/NZS 1580.108.1, ASTM B 499, ASTM D 7091, ASTM E 376, ASTM G 12,BS 5599,EN 13523-1, IMO MSC.215(82), IMO MSC.244 (83) |
| Display screen | 2.4 " (6 cm) QVGA color TFT display, 320x240 pixels |
| Operating temperature | 80℃ |
| Operating temperature | -10~50℃ |
| Battery life | With 1 reading per second, it can work continuously for up to 24h |
| Protection level | IP64 |
| supporting software | ElcoMaster ® Software |
| Machine Weight | 161G (including battery) |
| Machine size | 141*73*37mm |
Packing list
Thickness gauge host * 1, thickness gauge probe * 1, calibration shim * 6, zero board * 1, software * 1, carrying case * 1, protective cover * 1, lanyard * 1, USB cable * 1, factory certificate * 2, operation manual * 1, battery * 2
After-sales instructions
If the product quality is not caused by human beings, the manufacturer will provide one-year free warranty service (except for accessories and fragile consumables)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16627/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
