Defelsko PosiTector BHI3 Pap Hardness Tester (Premium)
SE
Positector BHI3
Defelsko Positector BHI3 Hardness TesterSPEC
Defelsko Positector BHI3 Hardness TesterDetails
Defelsko Positector BHI3 Hardness TesterPacking list
- SKU
- NB016630
- Measurement range
- 20 ~ 100 Barcol
- Resolution
- 0.1 Barcol
- Accuracy
- ± 2 Barcol
- Measuring tool size
- 137*61*28mm
- Measuring Weight
- 140g
- Probe size
- 145*97*64mm
- Probe headroom
- 140mm
- Probe Weight
- 400g
- Data storage
- 10W, 1000 sets
- Execution standards
- STM B648 / D2583, DIN EN 59和AS / NZS 3572.22
- Data Display
- Real-time rendering of measurement data
- data transmission
- Wifi, Bluetooth 4.0, BLE API can be used to integrate into third-party software
Measure the hardness of soft metals such as aluminum, aluminum alloys, copper, brass and other materials such as hard plastics and fiber-reinforced plastics
Easy-to-read digital display
Comparable to 934-1 Barcol Hardness Testers
The lightweight and portable device can be used in any orientation
PosiTector Interchangeable Platform - Connect any PosiTector probe to a single meter body
USB, WiFi, and Bluetooth connectivity with PosiSoft PC, Mac, and Smartphone software
Calibration certificate shows traceability to NIST (long form)
Complies with ASTM B648/D2583, DIN EN 59 and AS/NZS 3572.22
Features
Simple
Easy-to-read digital display
Comparable to 934-1 Barcol Hardness Testers
User-adjustable measurement time, on-screen countdown
Includes spare field-replaceable indenter with spare tool
The lightweight and portable device can be used in any orientation
The RESET function enables an immediate factory reset
durable
Solvents, acids, oils, water and dust - weatherproof
Shock-absorbing protective rubber holster with belt clip
Includes hard-shell carrying case
Two-year warranty on the meter body and probe
Accurate icons
accurate
A long calibration certificate is included
Hi-RES mode increases display resolution for use in applications that require greater precision
Includes hard and soft aluminum alloy test discs and calibration plates to verify gage operation
Complies with national and international standards, including ASTM
Multi-functional icons
versatility
The PosiTector body accepts all PosiTector BHI, SHD, 6000, 200, DPM, IRT, RTR, SPG, SST, and UTG probes from Hardness Testers for easy conversion to coating Thickness Gauges, dew point gauges, infrared thermometers, surface profile gauges, soluble salt Testers, or ultrasonic wall Thickness Gauges
1-point and 2-point calibration options with Cal Reset for factory reset
Selectable display language
High-contrast LCD with backlit display
Flip the display for a front-facing view
Use alkaline batteries or rechargeable batteries (built-in charger)
powerful
Mean, standard deviation, min/max hardness and readings are continuously displayed/updated while measuring
Screen Capture - Save an image of your screen for record-saving and viewing
When the measured value exceeds the user-specified limit, the HiLo alarm will sound and the alarm will be visible
Sealed USB port for quick and simple connection to PC and continuous power supply
PosiSoft USB Drive - Stored readings and graphics can be accessed using a universal PC/Mac web browser or file explorer. No software required.
Software updates over the network ensure that your gage is new
Software solutions for viewing, analyzing, and reporting data
Each stored measurement is marked with a date and time
Version differences
Standard
Includes all the features shown above plus ......
A storage of 250 readings per probe storage can be viewed or downloaded
Advanced
Includes all the features of the Standard Edition
Store 100,000 readings from multiple probes for up to 1,000 batches and sub-batches
Automatic Sub-Batches - Automatically create sub-batches after taking the required readings
Plot measurement data in real time
Bulk/Read Annotations - Use the on-screen QWERTY keyboard to add annotations and change batch names
Store thickness, profile, environmental, salt contamination, hardness, and wall thickness measurements in each batch
WiFi technology syncs wirelessly with PosiSoft.net and downloads software updates
Bluetooth 4.0 technology for data transfer to a mobile device running the PosiTector App or an optional portable printer. The BLE API can be used for integration into third-party software.
Integrate with third-party software, drones, ROVs, PLCs, and robotic devices using multiple industry-standard communication protocols
Typical Applications
Aluminum production
Forgings, castings, raw material inspection
FRP / GRP - Fiber & Glass Fiber Reinforced Plastics (Reinforced & Non-Reinforced Rigid Plastics)
Duro or hard thermoplastic
The degree to which the composite material is cured
