Specifications
| Measurement principle | Magnetic Induction |
| Measurement range | 0~5000μm |
| margin of error | ±3% |
| Resolution | 0.1μm|1μm |
| Minimum measurement surface | 25mm |
| Minimum radius of curvature | Convex 5mm; Concave 25mm |
| thinnest substrate | 0.2mm(F) |
| probe | Split probe |
| Probe material | ruby |
| Calibrated Certificate | Yes. |
| Calibrated mode | No need to calibrate |
| Unit display | μm |
| Interface | USB |
| Data storage | Temperature -10~60 ℃ (14~ 140 ° F) |
| Power Supply | 2 AA batteries |
| Standards | DIN EN ISO 2808, ISO 2178, ASTM B 499, ASTM D 7091 |
| Language | German, English |
| Display screen | LCD screen |
| Operating temperature | 0~50℃ |
| Machine Weight | 105g |
| Machine size | 100*60*27mm |
Packing list
Host X1, probe X1, user manual X1, plastic outer box X1, Calibration plate X1, 1.5V battery X2, test certificate X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by man-made, the manufacturer provides 1 year free warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16667/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
