Specifications
| Measurement principle | Magnetic Induction + eddy Current |
| Measurement range | Fe：0~5000μm；NFe：0~3000μm |
| margin of error | ±3% |
| resolution | 0.1μm|1μm |
| Minimum measurement surface | Φ25mm |
| Minimum radius of curvature | Convex 5mm; Concave 25mm |
| thinnest substrate | 0.2mm(F)；0.05mm(N) |
| probe | Split probe |
| Probe material | ruby |
| Unit display | μm/mils |
| Power Supply | 2 × 1.5V AA battery |
| Standards | DIN EN ISO 2808, ISO 2178, ASTM B 499, ASTM D 7091,SO 2360 |
| system language | German, English |
| Display screen | LCD screen |
| Operating temperature | -10~60℃ |
| Weight | 105g |
| Dimension | 100*60*27mm |
Packing list
Host X1, probe X1, user manual X1, plastic outer box X1, Calibration plate X1, 1.5V battery X2, test certificate X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16675/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
