Specifications
| Measurement principle | Magnetic Induction + eddy Current |
| Measurement range | 0~5000μm |
| margin of error | ≤1000μm：±(1+2%)μm、>1000μm：±3.5% |
| resolution | 0.1μm|1μm|0.01mm |
| Minimum measurement surface | 10*10mm |
| Minimum radius of curvature | Convex 5mm/Concave 25mm |
| thinnest substrate | 0.2mm(F)；0.05mm(N) |
| probe | Integrated probe |
| statistical function | Average value, max value, small value, standard deviation |
| Data storage | 3900 measurements, 999 data sets |
| Power Supply | 1 9V alkaline battery |
| system language | English |
| Display screen | LCD liquid crystal |
| Weight | 50g |
| Dimension | 166*64*34mm |
| Storage temperature | -10~60℃ |
| temperature compensation | 0~50℃ |
| Interface | Connect a computer or printer via USB and RS232 interfaces |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16680/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
