Specifications
| Dimensions | 155*60*38mm |
| Impact device | D type |
| Impact energy | 11mJ |
| Ball head material | Tungsten carbide |
| Measurement Accuracy | +/- 0.8% Actual Hardness |
| Maximum Hardness of Specimen | 980HV |
| Weight | 220g |
| Measurement direction | 360 ° (vertical down, diagonal down, horizontal, diagonal up, vertical up) |
| Operating temperature | 0~50℃ |
| Specimen minimum Weight | 5kg |
| Minimum radius of curvature of specimen | 10mm |
| Power Supply | 3.6V rechargeable lithium battery, Charging time 3 hours |
| Data storage | Maximum 500 groups |
| Interface | USB 1.1 |
Packing list
Host X1, test block X1, USB cable X1, software X1, instrument case X1, operation manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16711/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
