Specifications
| initial test force | 98.07N/10Kgf |
| Total test force | 588.4N/60Kgf, 980.7N/100Kgf, 1471N/150Kgf |
| Application of test force | fixed load |
| Control of test force | Hydraulic damping system |
| Measurement results show | Dial reading |
| Maximum test space in the vertical direction | 170mm |
| Horizontal indenter axis from front wall | 167.6mm |
| Dimension | 508*216*762mm |
| Net Weight | 110kg |
| execution standard | ASTM E-18 |
Packing list
Host X1, diamond indenter X1, steel ball indenter X1, Hardness test block X5, sample table X3, Accessories box X1, dust cover X1
After-sales instructions
Warranty days: 365 days
