Specifications
| initial test force | 29.4N（3kgf）, 98.1N (10kgf) |
| Total test force | 147.1N(15kgf), 294.3N(30kgf), 441.3N(45kgf),588.4N (60kgf), 980.7N (100kgf), 1471N (150kgf) |
| loading time | 2~ 50s, can be set/stored |
| resolution | 0.1HR |
| Display | High-precision backlit LCD display |
| Measurement space | 300Mm (vertical), 220mm (horizontal) |
| data statistics | Avg., Max., Min., S, R |
| Storage | 400 sets of measurement data are automatically stored |
| Power Supply | AC, 220V/110V, 50~60Hz, 4A (can be changed) |
| Net Weight | 86 kg (190lbs) |
| Power supply Voltage | AC, 220V/110V, 50~60Hz, 4A (can be changed) |
Packing list
Host X1, Hardness block X6, steel ball indenter X1, diamond conical indenter X1, indenter fixing screw X2, sample table X2, power cord X1, wrench X1, dust cover X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16734/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
