Specifications
| test force | 62.5kgf, 100kgf, 125kgf, 187.5kgf, 250kgf, 500kgf, 750kgf, 1000kgf, 1500kgf, 3000kgf |
| Hardness testing range | 3.18~653HBW |
| Test loading force application method | Automatic (load/hold/unload) |
| Hardness reading | Display indentation, touch screen automatically gets Hardness value |
| computer system | CPU: Intel I3, Memory: 2G, SSD: 32G |
| Hardness system that can be converted | HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HS, HBS, HBW |
| Interface | Built-in USB interface, VGA interface, network interface |
| Objective lens and indenter switching | Automatic identification and automatic switching of three indenter and double objective lenses |
| objective lens | 1× ，2× |
| Microscope magnification | 20X，40X |
| resolution | 1.25μm ，0.625μm |
| Load time | 0~95s |
| Maximum test space in the vertical direction | 260mm |
| The maximum distance from the center of the indenter in the horizontal direction to the outer wall | 150mm |
| Power Supply | AC220V，50Hz |
| execution standard | ISO 6506，ASTM E10-12，JIS Z2243，GB/T 231.2 |
| Dimension | 600*330*890mm |
| Outer box size | 820×460×1170mm |
| Net Weight | 150kg |
| Gross Weight | 180kg |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
