Specifications
| Test force Nm | 98, 245, 490, 980, 1960, 2940, 4900, 9800 Nm |
| Test force gf | 10, 25, 50,100, 200, 300, 500, 1000(1K) gf |
| Vickers Hardness | HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1 |
| Knoop Hardness System | HK0.01, HK0.025, HK0.05, HK0.1, HK0.2, HK0.3, HK0.5, HK1 |
| Test method | HV / HK |
| language | English/Chinese |
| Test force application method | Automatic (loading/loading/unloading) |
| X-Y test bench size | 100*100mm |
| X-Y test bench itinerary | 25*25 mm |
| X-Y test sample stage rotation scale | 0.002mm |
| Hardness conversion | Multiple Hardness Conversion Options |
| Test force holding time | 0~90s (every 5 seconds is an adjustment order) |
| Turret | Switching between indenter and objective, automatic and manual optional |
| contrast ratio | Adjustable |
| Maximum test space in the vertical direction | 90mm |
| The maximum distance from the center of the indenter in the horizontal direction to the outer wall | 120mm |
| Power Supply | AC110/220V, 60/50Hz |
| Guaranteed size | 495×305×550mm |
| Net Weight | 33kg |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16738/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
