Specifications
| Measurement range | 0.5~300mm |
| Probe style | Integrated probe |
| Probe Frequency | 5MHz |
| Speed of sound | 1000~9999m/s |
| measurement error | ±(0.5%H+0.04)mm |
| Display resolution | 0.1/0.01mm |
| Data storage | 20 groups (100/group) |
| Operating language | Chinese |
| Display | 4-Bit LCD with backlight |
| Host size | 150*74*33mm |
| Weight | 245g |
| Application | Steel, Titanium, Plastic Products, Ceramics, Glass and Miscellaneous Ultrasonic Conductors |
| Power Supply | 2 * 3V AA alkaline battery |
| Max/min alarm preset | Yes. |
| Environmental temperature | 0~50℃ |
| Probe Frequency | 4Hz |
| Interface | USB |
| micro printer | optional |
| Operating Time | More than 100h (when the backlight is not turned on) |
| Power consumption | Operating current not more than 3v |
Packing list
Host X1, straight probe X1, data cable X1, No. 5 battery X2, coupling agent X1, U disk X1, calibrate certificate X1, hand box X1, manual X1, certificate X1, warranty card X1
