Specifications
| test range | 1HV~2967HV |
| test force | 0.098N(10g)、0.246N（25g）、0.49N（50g）、0.98N（100g） 1.96N（200g）、4.90N（500g）、9.80N（1000g） |
| The maximum height of the sample that can be tested | 70mm |
| The maximum distance from the center of the indenter to the outer wall | 95mm |
| Switching of indenter | Manual turret |
| Test force application method | Automatic (load/hold/unload) |
| Microscope magnification | 100X、400X |
| Test force holding time | 5~60s |
| Minimum Graduation of micrometer drum | 0.25um |
| The size of the cross platform | 100×100mm |
| Movement range of the cross platform | 25×25mm |
| Light source/Power Supply | 110/220V, 60/50Hz/cold light |
| Gross Weight | 41.5kg |
| Net Weight | 35kg |
| Packaging Dimensions | 425×245×490mm |
Packing list
Host (automatic turret) X1, cross platform X1, sheet clip platform X1, filament clip platform X1, flat clip platform X1, manual measurement software X1, USB cable X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16754/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
