Specifications
| Lighting method | 8°/d |
| Sensors | Integrated photodiode array |
| Measurement Range | L:0~100 |
| Measurement light source | D65 |
| Measurement time | 1.0s |
| Measurement caliber | Φ8mm |
| Sexual repeability | ΔE*ab<0.08 |
| operating language | Simplified Chinese, English |
| Data Interface | USB 2.0 (USB-B type), RS-232 (115200bps) |
| Viewing Angle | CIE 10° |
| color difference formula | ΔE*ab |
| data storage | 100 master standard data, 100 sample data under each master standard |
| Power Supply | Lithium battery can be measured 5000 times after being fully charged |
| display mode | CIELAB |
| Operating environment | 0 ℃ -40 ℃ (32 ° F -104 ° F); Relative Humidity below 85% without condensation |
| Storage environment | -20℃-50℃ |
| Dimensions | 199*68*90mm |
| Weight | 700g |
| Inter-instrument Agreement | ΔE*ab<0.2 |
| Lighting source life | More than 1.60 million measurements in 5 years |
| Display | TFT True Color 2.8inch @(16:9) |
| packing size | 400*240*340mm |
| Standard Accessories | 3000mAH lithium battery, power adapter, manual, warranty card. |
| optional accessories | Powder test box, micro printer |
Packing list
Host X1, White Calibration plate X1, Data cable X1, Manual X1, Warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16874/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
