Specifications
| Lighting method | D/8 (Scattering Light source, 8 degree Viewing Angle) SCS Optical inspection engine (spectroscopic integration system), ETC (real-time calibrating technology), with SCI (including specular reflection component)/SCE (excluding specular reflection component) synchronous measurement function. |
| Sensors | Blue Light Enhanced Array Sensors |
| Available Light Sources | A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,DLF,TL83,TL84,NBF,U30,CWF |
| Measurement time | 1s |
| Measurement caliber | Φ8mm |
| Spectroscopic reflectance Repeatability | Standard deviation within 0.08% |
| Operating language | Chinese, English |
| Interface | USB |
| Viewing Angle | CIE 2°/10° |
| Available Light Sources | CLEDs (Full Band Equalized Led Light sources) |
| Color difference formula | ΔE*ab,ΔE*CH,ΔE*uv,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*94,ΔE*00 |
| data storage | 20,000 pieces of test data |
| Power supply Voltage | Charging, repeability, continuous measurement 10000 times, 7.4V/6000mAh |
| display mode | Light spectrum map/data, sample chromatic value, color difference value/map, pass/fail result, Color bias, Color simulation, Display measurement area, Historical data color simulation, Manual input standard sample, Generate test report |
| Operating environment | 0~45 ℃, Relative Humidity 80% or less (at 35 ℃), no water condensation |
| Storage environment | -25~ 55 ℃, Relative Humidity 80% or less (at 35 ℃), no water condensation |
| Dimensions | 181*73*112mm |
| Weight | About 550g (without battery) |
| Integrating sphere size | Φ40mm |
| Wavelength range | 400~700nm |
| wavelength interval | 10nm |
| Light spectrum Bandwidth | 5nm |
| Reflectance Measurement Range | 0~200% |
| Reflectance resolution | 0.01% |
| Measurement time | About 2s |
| Color Space | CIE-L * a * b, L * C * h, L * u * v, XYZ, Yxy, reflectance |
| Lighting source life | 5 years 1.50 million times |
| Inter-instrument Agreement | ΔE*ab<0.2 |
| Display | Full color true color screen |
| Color scheme | Unmatched |
| UV Light source | No UV Light source |
| Chroma indicator | WI、YI、TI |
| Chroma indicator | Homochromatic index MI, colour fastness, discoloration fastness |
| Repeatability of chromatic value | Delta E * ab within 0.03, MAX Maximum: 0.05 |
Packing list
After-sales instructions
Warranty days: 1095 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16877/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
