Specifications
| Standard throughput | 100~8000mL(28G)：150~10000mL(36G) |
| Speed regulation | stepless speed regulation |
| Rotor maximum linear speed | 19m/s(28G)；27m/s(36G) |
| output power | 350W |
| Power | AC220V 50/60Hz |
| Speed range | 300~18000rpm |
| Work head specification | 28G：Φ28mm，L230mm；36G：Φ36mm，L235mm |
| Work head material | SS304 |
| Maximum Max. Viscosity | 28G：6000mPa.s，36G：8000mPa.s |
| Allowable environment temperature | ≤120℃ |
| Allowable Relative Humidity | ≤80% |
| Dimensions | 215*310*720mm |
| Total Weight | 9.7kg |
| Speed dynamic detection function | Yes |
| Overload protection | Yes. |
| Minimum immersion liquid height | 50mm(28G)；60mm(36G) |
| Bearing material | PTFE |
| Maximum immersion liquid height | 150mm(28G)，160mm(36G) |
Packing list
Host X1, working head X2, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16909/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
