Specifications
| Display | 128 * 64 LCD, Chinese display |
| Measurement range | 0.00~20.00mg/L |
| Accuracy | ±1.5%FS |
| Resolution | 0.01mg/L |
| Repeatability | ≤1% |
| Temperature sensor | PT1000 |
| Response time | T90<5min (25℃) |
| Temperature compensation range | 0~60℃ |
| Water sample temperature | 5~60℃ |
| Environmental temperature | 5~45℃ |
| Working Relative Humidity | ≤ 90RH (non-condensing) |
| Storage temperature | -25~ 55 ℃ (electrode should be higher than 0 ℃) |
| Power Supply | AC (85~ 265) V Frequency (45~ 65) Hz |
| current output | 0~10mA, 0~20mA, 4~ 20mA optional, load < 300Ω |
| Alarm relay | AC220V 3A /DC30V 3A |
| power consumption | ≤15W |
| Protection level | IP65 |
| Dimensions | 145*120*150mm |
| opening size | 138*138mm |
| Weight | 0.64kg |
Packing list
Host X1, dissolved oxygen composite electrode X1, sewage electrode flow tank X1, main board X1, online shell X1, fine steel wire X1, electrode extension wire X1, electrode film head X1, pipeline mounting kit X1, flange mounting kit X1, 1 meter submerged kit X1, 1 meter extension tube kit X1,
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16970/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
