Specifications
| Display | 128 * 64 LCD, Chinese display |
| Measurement range | 0.00~20.00mg/L |
| Accuracy | ±1.5%FS |
| Resolution | 0.01mg/L |
| Response time | T90<5min (25℃) |
| Automatic temperature compensation | 0~60℃ |
| Water sample temperature | 5~45℃ |
| Environmental temperature | 0~60℃ |
| Working Relative Humidity | ≤ 90% RH (non-condensing) |
| Storage temperature | -25~ 55 ℃ (electrode should be higher than 0 ℃) |
| Power Supply | AC (85~ 265) V Frequency (45~ 65) Hz |
| current output | 0~10mA, 0~20mA, 4~ 20mA optional, load < 300Ω |
| Alarm relay | AC220V 3A /DC30V 3A |
| power consumption | ≤15W |
| Protection level | IP65 |
| Power down save | > 10 years |
| Dimensions | 98*130*98mm |
| opening size | 94*94mm |
| Weight | 0.5kg |
Packing list
Host X1, dissolved oxygen composite electrode X1, main board X1, online shell X1, fine steel wire X1, electrode extension wire X1, electrode film head X1, 1 meter immersion kit X1, 1 meter extension tube kit X1, flange mounting kit X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/16973/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
