Specifications
| Measurement range | 0~3000 μS/cm and 0~30000 μS/cm |
| Measurement error | ±2.5% F.S |
| Resolution | 0.001μS/cm |
| Temperature compensation range | 0~60℃ |
| Dimensions | 145*120*150mm |
| Weight | 0.64kg |
| Display | 128X64 dot matrix LCD, Chinese display |
| Repeatability | ≤1% |
| Temperature sensor | Pt1000 |
| Water sample temperature | 5~60℃ |
| water sample pressure | <0.6 Mpa |
| Operating temperature | 5~45℃ |
| Operating humidity | ≤ 90% RH (non-condensing) |
| Storage temperature | -25~55℃ |
| Protection level | IP65 |
| Power down save | > 10 years |
| Current Output | 0~10mA, 0~20mA, 4~ 20mA optional, load < 300Ω |
| Alarm relay | 2 normally open points can be set arbitrarily, AC 220V 3A/DC 30V 3A |
| output load Capacity | ≤750Ω |
| Output Accuracy | 1%F.S |
| Relay load Capacity | AC 250V 5A/DC 30V 5A |
| Power Supply | AC (85~ 265) V Frequency (45~ 65) Hz |
| Power | ≤ 15W |
| opening size | 138mm×138mm |
Packing list
Host X1, conductivity composite electrode (k = 10) X1, 5 meters X1
After-sales instructions
Warranty days: 365 days
