Specifications
| Display | 5.0 inch touch color LCD, Chinese display |
| PH range | 0.00~14.00pH |
| Error of indication | ±0.02 pH |
| Resolution | 0.01pH |
| Impedance | ≥1X10^12Ω |
| Repeatability | ≤1% |
| Stability (zero drift) | ±1%F.S/4h |
| Response time | T90<1min (25℃) |
| Temperature sensor | Pt1000 |
| Measurement range | 0~60℃ |
| Water sample temperature | 5~60℃ |
| Environmental temperature | 5~45℃ |
| Allowable Relative Humidity | ≤ 90% RH (non-condensing) |
| Storage environment | -25~ 55 ℃ (excluding electrode, electrode should be higher than 0 ℃) |
| Power Supply | AC (85~ 265) V Frequency (45~ 65) Hz |
| Power | ≤ 5W |
| Dimensions | 200*200*85mm |
| Weight | 2.1kg |
Packing list
Host X1, pH three composite electrode (ordinary water/sewage) X1, pH buffer (analytical pure) X1, electrode bracket X1, back cover X1, short circuit head X1, three-core power cord X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17017/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
