Specifications
| Display | 5.0 inch touch color LCD, Chinese display |
| Measurement range | 0.00~20.00mg/L |
| Accuracy | ±1.5%FS |
| Resolution | 0.01mg/L |
| Repeatability | ≤1% |
| Stability | ±1%FS/4h |
| Response time | T90<5min (25℃) |
| Temperature sensor | Pt1000 |
| Temperature compensation range | 0~60℃ |
| Water sample temperature | 5~45℃ |
| Environmental temperature | 5~45℃ |
| Working Relative Humidity | ≤ 90% RH (non-condensing) |
| Storage temperature | -25~ 55 ℃ (excluding electrode, electrode should be higher than 0 ℃) |
| Power Supply | AC(220±22) V (50±1)Hz |
| power consumption | ≤5W |
| Dimensions | 200*200*85mm |
| Weight | 2.1kg |
Packing list
Host X1, dissolved Oxygen composite electrode X1, dissolved Oxygen electrode filler X1, electrode film head X1, electrode holder X1, three-core power cord X1
After-sales instructions
Warranty days: 365 days
