Specifications
| application | Crushing, grinding, mixing, homogenizing, polishing, etc |
| Application | Electronics, Medical, Beauty, Chemical, Pottery and porcelain, Glass, Metallurgy, Teaching, Research, etc |
| Sample characteristics | Hard, brittle, drying, wet, viscous, fibrous, flowability, corrosion and oxidation, etc |
| Processing principle | Friction, impact force |
| Dry grinding | Yes |
| wet grinding | Yes |
| vacuum mill | optional |
| Low temperature mill | optional |
| Smash time | 15-20min |
| Maximum feed size | Soil material ≤ 10mm, Miscellaneous material ≤ 3mm |
| Minimum discharge particle size | 0.1µm |
| Maximum throughput | 1000ml |
| station number | 4pcs |
| speed ratio | 2:1 |
| Ball mill tank speed | 800rpm |
| Planetary disk diameter | 340mm |
| Film thickness | 6mm |
| Type of ball mill | Conventional type, vacuum type |
| Ball mill material | Stainless steel, nylon, polypropylene, ultra-high density polyethylene, PTFE, polyurethane, corundum, zirconium oxidation, agate, cemented carbide, etc |
| Grinding tank size | 250ml |
| Grinding material | Stainless steel, aluminum oxidation, zirconia, agate, cemented carbide |
| Grinding ball size | 2~30mm |
| Function Mode | Forward running (time can be set), reverse running (time can be set), forward and reverse running alternately, intermittent running (time can be set), Timer grinding (time can be set), pause, stepless speed regulation, emergency stop, restore |
| Ground time setting | Digital display, 00:00:01 to 99:59:59 |
| Intermittent run time setting | Digital display, 00:01:00~99:59:59 |
| Intermittent run time setting | Digital display, 00:00:01~ 99:59:59 |
| driver | Frequency converter, three-phase AC motor |
| Drive power | 0.75kw |
| Power | 110-120V / 220-240V |
| frequency | 50-60Hz |
| Power Connector | single phase |
| Dimensions | 720*468*535mm |
| Net Weight | 75kg |
| Gross Weight | 95kg |
| Protection class | IP53 |
| standard | CE |
Packing list
completeness-built unit X1, pressure rod X1, tool X1, lubricant X1, manual X1, warranty card X1, certificate X1
After-sales instructions
Warranty days: 365 days
1. The warranty period of the product is one year from the date of receipt.
2. Warranty method: repair the original product.
3. Time limit for the completion of warranty service: If the original product is repaired, the customer will be replied to the product maintenance within 3 working days from the date of receipt of the faulty product. If it is repaired, the repair will be completed and sent out within 7 working days from the date of receipt of the faulty product;
4. The above product quality warranty problems are not caused by human factors.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17052/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
