Specifications
| measurement principle | Magnetic Induction + eddy Current |
| Measurement Range | 0~1250μm |
| margin of error | ±2% |
| resolution | 0.1μm |
| Calibrated mode | Single point calibrated and two point calibrated |
| statistical function | Single measurement, continuous measurement |
| Unit display | μm/mils |
| statistical function | Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation |
| Data Interface | USB communication interface, can connect and communicate with PC |
| data storage | Can store 5 sets (up to 100 measurements each) measurement data |
| Power Supply | 3V (2 AA alkaline batteries) |
| Display screen | 128 * 64 dot matrix liquid crystal LCD |
| operating temperature | -20~50℃ |
| Relative Humidity | ≤90%RH |
| operating temperature | The surrounding environment has no strong vibration, no strong magnetic field, no corrosive medium and serious dust |
| battery life | More than 200h (when the backlight is not turned on) |
| Weight | 340g |
| Dimensions | 115*67*31mm |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17127/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
