Specifications
| Measurement range | 0.63~500mm |
| Probe Frequency | 5MHz |
| Probe diameter | Φ6.35mm |
| Display resolution | 0.01mm |
| unit system | mm/inch |
| Calibration method | Dialog Probe, Automatic calibration |
| Speed of sound | 1250~10000m/s |
| Standards | DB 37/T1846-2011、JJF 1126-2004 |
| Display | LCD display with backlight |
| Operating language | Chinese |
| Interface | USB |
| Protection level | 6-Key waterproof and oil-proof keyboard |
| Environmental temperature | -20~50℃ |
| Power Supply | 3V (2 AA size alkaline batteries) continuous use time up to 200 hours, when the battery Power Supply is insufficient, the display will flash alarm until automatic shutdown |
| Host size | 63.5*116*31.5mm |
| Weight | 300g |
| scanning method | 16 points per second measurement, can capture the thinnest point |
| error of indication | H ＋ +/- （ 0.5% 0.05) mm, H is the actual thickness of the measured object |
| Measurement mode | Dual Crystal Probe, Pulsed Echo |
Packing list
The whole machine x1, the operation manual x1, and the certificate of conformity x1.
After-sales instructions
Warranty days: 365 days
