Specifications
| Optical inspection system | Aberration Elimination (1200L/mm Grating) |
| Light spectrum bandwidth | 4.0nm |
| Wavelength range | 325~1000nm |
| Wavelength Accuracy | ±1.0nm |
| Wavelength Repeatability | ≤0.5nm |
| Photometric range | 0~200%T、-0.301~2.000A、0~1999C |
| Photometric Accuracy | ±0.002A(0~0.5A)、±0.003A(0.5~1A)、±0.5%T |
| Luminosity, sexual repeability | ≤0.3%T(0~100%T)；0.001A(0~0.5A)；0.002A(0.5~1A) |
| stray light | ≤0.3%T@360nm |
| Noise level | 100%≤0.15%T；0%≤0.1%T |
| Data Interface | RS232 interface and PC software |
| printout | RS232 print interface |
| light source | Tungsten Halogen Lamp |
| Dimensions | 450*340*180mm |
| Weight | 10kg |
| Drift | ≤0.001A/h@500nm |
Packing list
completeness-built unit X1, software X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The manufacturer provides a 1-year free warranty (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17239/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
