Specifications
| Optical inspection system | Aberration (1200L/mm Grating) |
| Light spectrum Bandwidth | 4.0nm |
| Wavelength range | 325~1100nm |
| Wavelength Precision | ±1.0nm |
| Wavelength Repeatability | ≤0.5nm |
| Photometric Range | 0~200%T、-0.301~3.000A、0~9999C |
| Photometric Precision | ±0.002A(0~0.5A)、±0.003A(0.5~1A)、±0.5%T |
| Luminosity Repeatability | ≤0.2%T(0~100%T)；0.001A(0~0.5A)；0.002A(0.5~1A) |
| stray light | ≤0.1%T@360nm |
| Noise level | 100%≤0.15%T；0%≤0.1%T |
| Baseline flatness | ±0.002A |
| Interface | USB interface and PC software |
| printout | Parallel entrance |
| Light source | Tungsten halogen lamp |
| Dimension | 450*340*180mm |
| Weight | 12kg |
| drift | ≤0.001A/h@500nm |
| scanning speed | Fast, medium, slow. |
Packing list
host X1, software X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The manufacturer provides a 1-year free warranty (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17242/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
