Specifications
| Optical inspection system | Aberration Elimination (1200L/mm Grating) |
| Light spectrum bandwidth | 4nm |
| Wavelength range | 195m~1000nm |
| Wavelength Accuracy | ±2nm |
| Wavelength Repeatability | ≤1.0nm |
| Photometric range | 0~200.0%T、0~1.999A |
| Photometric Accuracy | ±0.5%T |
| Luminosity, sexual repeability | ≤0.2%T |
| stray light | ≤0.3%T@220nm,360nm |
| Operating Mode | Transmittance, Absorbance, Concentration Factor, Concentration Direct Reading |
| printout | Serial port |
| Analysis software | optional |
| light source | Deuterium lamp, tungsten halogen lamp |
| Concentration range | 0~1999 |
| Drift | ≤0.002A/h@500nm |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The manufacturer provides a 1-year free warranty (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17247/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
