Specifications
| Optical inspection system | Aberration Elimination (1200L/mm Grating) |
| Light spectrum bandwidth | 2nm |
| Wavelength range | 190~1100nm |
| Wavelength Accuracy | ±0.5nm |
| Wavelength Repeatability | ≤0.3nm |
| Photometric range | 0~200%T、-0.301~3.000A、0~9999C |
| Photometric Accuracy | ±0.002A(0~0.5A)、±0.003A(0.5~1A)、±0.5%T(0~100%T) |
| Luminosity, sexual repeability | ≤±0.2%T(0~100%T)；0.001A(0~0.5A)；0.002A(0.5~1A) |
| stray light | ≤0.05%T@220nm,360nm |
| Noise level | 100%≤0.15%T；0%≤0.01%T |
| Baseline flatness | ±0.002A |
| Data Interface | USB interface |
| printout | Parallel port |
| light source | Deuterium lamp, tungsten halogen lamp |
| Concentration range | 0~1999 |
| Drift | ≤0.001A/h@500nm |
| Scanning speed | Fast, medium, slow |
| display | High-quality 128x64-bit graph LCD |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The manufacturer provides a 1-year free warranty (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17251/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
