Specifications
| Optical inspection system | Proportional double beam of light, 1200/mm Holographic grating |
| Light spectrum bandwidth | 2nm |
| Wavelength range | 190~1100nm |
| Wavelength Accuracy | ±0.5nm |
| Wavelength Repeatability | ≤0.2nm |
| Photometric range | 0.0%~200.0%T、-0.301~4.000A |
| Photometric Accuracy | ±0.5%T |
| Luminosity, sexual repeability | ≤0.2%T |
| stray light | ≤0.15%T@220nm,360nm |
| Noise level | 100%(T):≤0.2%(T) 0%(T)：≤0.1%(T) |
| Baseline flatness | ±0.002A (200nm ~1090nm) |
| printout | RS232 print interface |
| light source | Deuterium lamp, tungsten halogen lamp |
| Drift | ≤0.0009A/0.5h@250nm、500nm |
| Environment temperature | 5 ℃~35℃，≤85% |
| Scanning speed | Fast, medium, slow |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The manufacturer provides a 1-year free warranty (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17256/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
