Specifications
| Measurement Range | 0.5~400mm |
| Probe frequency | 5MHz |
| probe diameter | Φ10mm |
| Probe contact temperature | -10~60℃ |
| Lower limit of pipe measurement | Φ20*3mm |
| measurement error | ±0.05mm(≤10mm)；(±0.5%H+0.01)mm(>10mm) |
| Display resolution | 0.1/0.01mm |
| unit system | Metric/Imperial |
| Calibrated | Zero point calibrated, two point calibrated |
| storage Capacity | 500 sets of data; 5 files (100 sets of data per file) |
| Sound speed range | 1000~9999m/s |
| Display | 128 × 64LCD display, high luminance EL backlight |
| Data Interface | RS232 |
| Power Supply | 2 AA alkaline batteries 1.5V |
| Operating Time | 100h |
| Host size | 150*74*32mm |
| Weight | 238g |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17292/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
