Specifications
| Max. Capacity of stirring | 20L |
| Stirring speed | 100~1500rpm |
| Temperature range | RT+~340℃ |
| Timer | 1~5999min |
| Mixer size | 80mm |
| Dimensions | 160*280*85mm |
| Machine Weight | 2.8kg |
| Panel Material | Stainless steel ceramic coating |
| Motor type | DC brushless motor |
| Input Power | 18W |
| output power | 10W |
| Heating power | 550W |
| Power | 100~120/200~240V |
| Rated Frequency | 50/60Hz |
| station number | 1 station |
| Display mode | LCD |
| Rotation speed Display resolution | ±1 |
| Heating power | 500w |
| Temperature control Accuracy | ±1（＜100℃）±1%（＞100℃） |
| Safety protection temperature | 360℃ |
| Display resolution | ±0.1℃ |
| Temperature transducer | PT1000 |
| External temperature transducer temperature control Accuracy | Pt1000:±0.2℃ |
| Waste heat warning function | 50℃ |
| Interface | RS-232 |
| Protection level | IP42 |
| Ambient Temperature | 5~40℃ |
| Allowable Relative Humidity | 80% |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17327/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
