Specifications
| Measurement range | 30.6~102.6HS、170~960HLD、19~651HB、13.5~101.7HRB、17.9~69.5HRC、59.1~88HRA、80~1042HV |
| Measurement direction | 360 ° (vertical down, diagonal down, horizontal, diagonal up, vertical up) |
| Measurement material | Steel and cast steel, alloy tool steel, stainless steel, gray cast iron, ductile cast iron, cast aluminum alloy, copper zinc alloy (brass), copper tin alloy (bronze), pure copper, wrought copper |
| Error of indication | ±6HLD |
| Indication Repeatability | ±6HLD |
| Hardness system | HL/HB/HRC/HRA/HV/HS |
| Upper and lower limit setting range | 170~960HLD |
| Display | Highlight OLED128x64 dot matrix display |
| Indication calibrated | Adjustment with indication software |
| Data storage | Maximum 600 Groups (Impact 32~ 1) |
| Communication interface | USB 2.0 |
| Working time | About 200 hours |
| Power Supply | 7.4V nickel-metal hydride battery pack |
| Charging time | 2.5 to 3.5 hours |
| Print function | Thermal printer |
| working language | Chinese |
| Charging Voltage | 9V/1500mmA |
| Dimensions | 209 * 85 * 45Mm (host) |
| Weight | 0.3KG (host) |
Packing list
Host X1, D-type Impact device X1, D-type Richter Hardness block X1, nylon brush AX1, small support ring X1, communication cable X1, operation manual X1, printing roll X1, background software CD X1, instrument case X1, charger X1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17373/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
