Specifications
| Optical inspection system | Double beam of light ratio monitoring |
| Light spectrum Bandwidth | 2nm |
| Wavelength range | 190~1100nm |
| Wavelength Precision | ±2nm |
| Wavelength Repeatability | ≤0.5nm |
| Photometric range | 0~200%T、-0.3-3A、0~9999C |
| Photometric Precision | ±0.5%T |
| Luminosity Repeatability | ≤0.3%T |
| stray light | ≤0.1%T@220nm.360nm |
| Stability | ±0.002A/30min@500nm |
| Interface | USB port |
| printout | Parallel port |
| monitor | 128 * 64 check point array large screen LCD |
| Light source | Tungsten lamp, deuterium lamp |
| Power Supply | AC 85V~250V |
| Dimensions | 460*380*220mm |
| Weight | 18kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17538/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
