Specifications
| Optical inspection system | Double beam of light ratio monitoring |
| Light spectrum Bandwidth | 1nm |
| Wavelength range | 190~1100nm |
| Wavelength Precision | +/- 0.1nm@656.1nm, +/- 0.3nm full area |
| Wavelength Repeatability | ≤0.1nm |
| Photometric range | 0~200%T、-0.4-4.0A、0~9999C |
| Photometric Precision | ±0.2%T(0-100%T)；±0.002Abs(0-0.5Abs)；±0.004Abs(0.5-1.0Abs) |
| Luminosity Repeatability | ≤0.1%T(0~100%T)；±0.001A(0~0.5A)；±0.002A(0.5~1A) |
| stray light | ≤0.03%T@220nm，360nm |
| Noise level | ±0.0004A |
| Baseline drift | 0.0005A/h@500nm |
| Baseline flatness | ±0.001A |
| Interface | USB port |
| printout | Parallel port |
| monitor | 320 * 240 check point array large screen LCD liquid crystal display |
| Light source | Tungsten lamp, deuterium lamp |
| Detector | Imported silicon photodiode |
| Power Supply | AC 220V/50Hz或110V/60Hz |
| Dimensions | 625*430*210mm |
| Weight | 28kg |
| PC software | Standard |
Packing list
whole machine X1, analysis software X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17548/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
