Specifications
| Measurement principle | ultrasound |
| Measurement range | 50~7600μm |
| margin of error | ±3% |
| application | Thick, soft coatings such as polyurea, asphalt, neoprene, very thick polymers |
| Calibrated Certificate | Traceable to NIST or PTB (long form) |
| statistical function | Multi-layer coating system for measurement of up to 3 layers |
| Unit display | μm/mils |
| statistical function | MAX Maximum, MIN Minimum, Average, Standard deviation |
| icon function | Yes. |
| Interface | COR4.0,Positector APP,ALE API |
| Data storage | 250000 Measured values, 1000 groups |
| Power Supply | Alkaline or rechargeable batteries |
| Standards | ASTM D6132、ISO 2808 |
| Language | 16 languages including Chinese and English are available |
| Print function | Bluetooth printer (to be purchased separately) |
| supporting software | PosiSoft PC、PosiTector App |
| Machine Weight | 140G (without battery) |
| Machine size | 135*61*28mm |
Packing list
host x1, probe x1, standard foil x1, coupling agent x1, rubber protective cover with waist clip x1, No. 7 battery x3, nylon portable soft bag x1, English manual x1, certificate x1.
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer will be free of charge during the warranty period, and only the cost of spare parts will be charged outside the warranty period;
1-year warranty for the host and 6-month warranty for the probe, except for other accessories and consumables;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/17922/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
