Specifications
| maximum temperature | 1200℃ |
| Temperature range | 1000℃ |
| Heating Elements | resistance wire |
| Furnace Volume | 10L |
| Heating power | 3KW |
| Temperature control Accuracy | ±1℃ |
| Heating rate | ≦10℃/min |
| Thermocouple | Thermocouple K |
| Furnace size | Φ200*340mm |
| Power supply Voltage | AC220V |
| Dimension | 7600*800*900mm |
| Ultimate Vacuum | 10^-2 ~10^-5torr |
| Standard | Mechanical pressure gauge: -0.1 to 0.15 MPa |
Packing list
host X1, mechanical pressure gauge X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/18065/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
