Specifications
| maximum temperature | 1200℃ |
| Temperature range | 1000℃ |
| Heating Elements | resistance wire |
| Furnace material | aluminum oxide |
| Furnace Volume | 36L |
| Heating power | 9KW |
| Temperature control Accuracy | ±1℃ |
| Heating rate | ≦10℃/min |
| Thermocouple | Thermocouple K |
| Furnace size | 400*300*300mm |
| Power supply Voltage | AC380V |
| Chill down system | Air-cooled and water-cooled |
| Gas Control - Flow rate meter | N2:0 ~3.5L/min,H2:0 ~3.5LL/ min |
| Standard | mechanical vacuum pump |
| Flow velocity of water-cooled machine | 16L/min |
| Air pressure control | 0.01-0.02 Mpa |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/18067/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
