Specifications
| maximum temperature | 1700℃ |
| Temperature range | 1600℃ |
| Heating Elements | Silicon molybdenum rod |
| Furnace material | Aluminum oxidation |
| furnace Volume | 80L |
| Heating power | 25KW |
| temperature control Accuracy | ±1℃ |
| Heating rate | <20℃/min |
| thermocouple | Type B thermocouple |
| Furnace size | 500*400*400mm |
| Power | 380V |
| Chill down the system | Air and water cooling |
| Pressure control | 0.01-0.02 Mpa |
| Gas Control - Flow Meters | N2:0 ~3.5L/min,H2:0 ~3.5LL/ min |
| Standard | Mechanical Vacuumpump |
| Water cooler flow rate | 16L/min |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
Free warranty for one year (except for consumable parts.) During the warranty period, if the failure occurs due to product quality problems, it will be repaired free of charge, and if the failure occurs due to non-product quality problems, only the cost of production and appropriate travel expenses will be charged, and the product will provide lifelong service and provide accessories and wearing parts.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/18076/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
