Specifications
| Measurement principle | Magnetic Induction + eddy Current |
| Measurement range | 0~200μm |
| Resolution | 0.1μm |
| probe | FN2.0 |
| Probe size | Φ14*83mm |
| Probe Weight | 70g |
| Calibrated mode | Working calibrated, zero calibrated, single foil calibrated; zero offset |
| statistical function | Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation |
| Interface | USB2.0 |
| Data storage | 2000 Measured values |
| Standards | DIN，ISO，ASTM，BS |
| system language | English, German, French, Italian, Spanish, Turkish, Czech and Chinese |
| Display screen | High resolution color display |
| Operating temperature | 0~50℃ |
| Protection level | IP52 |
| Machine size | 137*66*23mm |
Packing list
Host, FN2.0 probe, rubber protective cover, 2 calibrated films, zero standard sheet (iron/aluminum), 2 AA batteries, PHYNIX.connect transmission software, user manual, manufacturer certificate, Encasement box
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/18273/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
