Specifications
| Measurement of plating | Standard configuration: chromium, nickel, copper, zinc, tin, silver, gold and other metal platings, composite platings (such as Cr/Ni/Cu), if you need to measure Miscellaneous platings, please ask in advance |
| Platings substrate | Metal, plastic, brass, zinc alloy, NdFeB, ceramics (basically not limited by the substrate) |
| Number of coating layers | Single layer and composite multi-layer |
| Minimum measurable size | φ 2.4mm and φ 1.7mm two sizes are standard, the plane is more than 3mm * 3mm, and the diameter of the circular shaft is more than 6mm. If you measure a smaller size workpiece, please submit it in advance. |
| Measurement range | 0~ 300μm (the use range is 0.03~ 50um, beyond 50um, the error will gradually increase) |
| Indication Error | ≤±10% |
| reproducibility | ≤5% |
| resolution | 0.01μm |
| power supply | AC 220V +/- 10%, 50/60Hz, 30W |
Packing list
Host X1, test rack X1, electrolysis solution (120ml) X4, dropper X10, eraser X1, forceps X1, paper towel X1, test rack fastening wrench X1, manual X1, warranty card X1, certificate X1
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer provides 1 year free warranty service
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/18407/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
