Specifications
| Sensors (PID) | 10.6 eV Ion Science grid electrode detection lamp |
| intrinsically safe certification | Hazardous area safety approval. ATEX: II 3 G Ex nA IIC T4 (-40 ℃ ≤ Ta ≤ 50 ℃); IECEX: II Ex ia IIC T4 (-20 ℃ ≤ Ta ≤ 50 ℃) |
| access protection level | IP-65 Wire Bushing; IP-45 Sensors |
| Power Supply | 5-28VDC, maximum 65mA |
| output | 4-20mA (requires 8-35VDC Power Supply) |
| range | 0~100ppm |
| resolution | 0.1ppm |
| Sampling method | Diffusion (External Electric Pump if required) |
| Display | 7-Section display, 4-digit digital LCD, 4-color LED |
| Response time | Sensors T90 < 5s, Detector - 1 minute (standard) |
| Accuracy | 0-100ppm ＞ 98％ |
| calibrate | Magnetic, calibrated with 100 ppm isobutylene by calibrating package |
| Operating temperature | -20℃~50℃（-4℉—122℉） |
| Operating humidity | 0~95% RH (non-condensing) |
| Weight | 1.3kg（2.9lb） |
| Encasement Weight | 1.47kg（3.2lb） |
| Dimension | 120*160*70mm |
| Sensors principle | PID |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/18425/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
