Specifications
| Two-speed (standard) | 750rpm = 10,000 s-1 900 rpm = 12,000 s-1 |
| Viscosity range | 5 cones/Measurement range: 0~5, 0~10, 0~20, 5~ 50, 10~100P |
| Viscosity resolution | 0.01 Poise |
| Measurement Accuracy | 0.01 Poise |
| Lamina temperature | 5~ 65 ℃ (built-in) |
| Temperature Resolution | +/- 0.1 ℃ (calibrated) |
| Temperature Accuracy | +/- 0.1 ℃ (calibrated) Not specified when Environmental temperature is below 15 ℃ |
| running time | 5~59s |
| Warm-up time | 0~59s |
| Power Supply system | 90-240V AC-50/60Hz |
| Application standard | BS 3900;A7, ASTM D 4287, ISO 2884. |
| Unit display | P,cP,Pa.s |
| Data storage | 100 readings |
| Interface | RS232 |
| Instrument material | cemented carbide |
| Display mode | 128 x 64 LCD |
| Dimensions | 350*300*555mm |
| Weight | About 15Kg |
| Storage temperature | -20~50℃ |
| Operating temperature | 15~ 35 ℃ (plate temperature 40~220 ℃) |
| Environment Relative Humidity | 20~80% RH non-condensing |
