Specifications
| Speed range | Rotation: 0~50rpm, adjustable; Stirring shaft/paddle speed: 0~80rpm, adjustable |
| Impeller type | Welded frame type, material: SUS304 |
| Processing Capacity | 250~500mL |
| With/Without Mixing Tank | Yes |
| Size in barrel | 120*100mm |
| Barrel Volume | 1.13L (liner material: SUS304) |
| Lifting stroke | 120mm |
| basic structure | Hydraulic lift, double mixing shaft + with scraping wall |
| Upper barrel body (kettle cover) - material | SUS304 |
| Upper barrel body (kettle cover) - accessories | Should 32 powder/liquid feeding hopper, can be quickly switched on and off; with 2 small windows, a vacuum pressure gauge, and Miscellaneous necessary nozzles (vacuum/vent/spare). |
| Motor Power | 0.55Kw/4P |
| Frequency converter Power | 0.75KW |
| Gear reducer | Matching cycloid gear reducer BL0, the reduction ratio is about I = 23, the use factor Fa = 1.0 |
| Wall scraper - material | SUS304 and Teflon, consistent with revolution speed |
| vacuum | ≤-0.098Mpa |
| Vacuum pump | 2X-2, 0.37kw/4P motor, for easy maintenance, vacuum pump user-provided |
| Vacuum pump - sealing | Mechanical sealing |
| Vacuum pump - static sealing | Using O-shaped sealing ring |
| Temperature measurement system | Temperature probe inserted on the side of the barrel |
| Power | 0.92KW |
| Rated Voltage | 380V/50Hz/3Phase |
| Rated Voltage | 220V |
Packing list
host X1, mixing bucket X1, power distribution cabinet X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
