Specifications
| Speed range | Rotation: 0~80rpm, adjustable; Stirring shaft/paddle speed: 0~110rpm, adjustable; Rotation speed: 0~3800rpm, adjustable; Linear speed: 0~8m/s |
| Impeller type | Spiral twist |
| Processing Capacity | 2L |
| maximum viscosity | 1000000mPa·s |
| With/Without Mixing Tank | Yes |
| Size in barrel | 180*150mm |
| Barrel Volume | 3.8L (liner material: SUS304) |
| Lifting stroke | 220mm |
| Dimensions of the whole machine | 900*900*1800mm |
| Machine Weight | About 300KG |
| basic structure | Single dispersion shaft + double stirring shaft + with scraping wall + temperature measuring shaft |
| Upper barrel body (kettle cover) - material | SUS304 |
| Upper barrel body (kettle cover) - accessories | A φ 40 powder/liquid filling hopper, which can be quickly switched on and off; 1 spotlight; with 2 small windows (a spotlight port and an observation hole), a vacuum pressure gauge, and Miscellaneous necessary nozzles (vacuum/vent/spare) |
| Motor Power | 0.75Kw/2P |
| Frequency converter Power | 0.75KW |
| Gear reducer | Matching cycloid gear reducer BL0, the reduction ratio is about I = 23, the use factor Fa = 1.0 |
| Wall scraper - material | SUS304 and Teflon, consistent with revolution speed |
| vacuum | ≤-0.098Mpa |
| Vacuum pump | 2X-2, 0.37kw/4P motor (vacuum pump is not guaranteed) |
| dispersion axis | One, a dispersion disc is installed on the dispersion shaft to ensure better dispersion/stirring, material: SUS304 |
| Impeller configuration | Φ50mm |
| Vacuum pump - sealing | Mechanical sealing |
| Vacuum pump - static sealing | Using O-shaped sealing ring |
| Measurement range | 0-300 ℃, the temperature probe moves with revolution and directly contacts the material (this method is a way to control the temperature by plus or minus 1 degree). |
| workbench | Stainless steel outsourced laboratory work platform |
| Power | 1.5KW |
| Rated Voltage | 380V/50Hz/3Phase |
| Rated Voltage | 220V |
| Lifting method | Electric lift |
| Impeller material | SUS304 |
Packing list
host X1, mixing bucket X1, power distribution cabinet X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
【Attention】
Because the product is not easy to damage the goods, within 7 days after the customer receives the goods, if it is not the quality of the product itself, there is no warranty period. If there is a quality problem after the customer receives the goods, he or she needs to take a photo and send it to the mall customer service, and replace it free of charge after confirming the problem.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/18585/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
