Specifications
| Optical inspection system | Single beam of light (1200/mm holographic light) |
| Light spectrum bandwidth | 1.8nm |
| Wavelength range | 190~1100nm |
| Wavelength Accuracy | +/- 0.1Nm (D2 656.1nm )， +/- 0.5nm full band |
| Wavelength Repeatability | ≤0.2nm |
| Wavelength resolution | 0.1nm |
| monitor | 320 * 240 graphic LCD monitor |
| stray light | ≤0.05%T@220nm,360nm |
| Photometric range | 0.200%T、 0.301-3.0A、 9999.9999C |
| Photometric Accuracy | ±0.002A(0~0.5A)、±0.004A(0.5~1A)、±0.008A(1~2A)、±0.3%T(0~100%T) |
| Luminosity Repeatability | ±0.15%T(0~100%T)；0.001A(0~0.5A)；0.002A(0.5~1A)；0.004A(1~2A) |
| Baseline flatness | ±0.002A |
| Baseline drift | Soil 0.002A/h (500nm, 0A, 2nm Light spectrum bandwidth, after 2h preheating) |
| photometric noise | ±0.0005A（500nm，0A，2h） |
| Interface | USB1.1 optional built-in printer/USB2.0 printer/U disk Data output |
| Dimensions | 569*448*230mm |
| Weight | 15KG |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
