Specifications
| Max. Capacity of stirring | 20L |
| Stirring speed | 100~1500rpm |
| Temperature range | RT+~340℃ |
| Stir size | ≤80mm |
| Pan size | Φ135mm |
| Dimensions | 160*280*85mm |
| Machine Weight | 2.8kg |
| Panel Material | Pottery and porcelain coatings |
| Motor type | DC brushless motor |
| input power | 18W |
| output power | 10W |
| Heating power | 550W |
| Power Supply | 100~120/200~240V 50/60Hz |
| Rated frequency | 50/60Hz |
| station number | 1 station |
| display mode | LCD |
| RPM display resolution | ±1rpm |
| Heating power | 500w |
| Temperature control Accuracy | ±1（＜100℃）±1%（＞100℃） |
| Safety protection temperature | 360℃ |
| Temperature display resolution | ±0.1℃ |
| Temperature transducer | PT1000 |
| External temperature transducer temperature control Accuracy | Pt1000:±0.2℃ |
| Waste heat warning function | 50℃ |
| Data Interface | RS-232 |
| Protection level | IP42 |
| Allowable environment temperature | 5~40℃ |
| Allowable Relative Humidity | 80% |
Packing list
Host X1, quality assurance card X1, certificate of conformity X1, manual X1
After-sales instructions
Warranty days: 730 days
