Specifications
| Measurement principle | Magnetic Induction + eddy Current |
| Measurement range | 0 ~ 1250µm |
| margin of error | ±1~3% |
| Resolution | 0.1mm | 1mm |
| Minimum radius of curvature | Convex 5mm; Concave 25mm |
| thinnest matrix | 0.3mm |
| probe | F and N split probes |
| Statistical function | Average, MAX Maximum, MIN Minimum, Number of Tests |
| icon function | without |
| Power | Three (7) alkaline batteries |
| Standards | GB/T 4956-1985 |
| Calibrated Certificate | without |
| Language | Chinese, English |
| Display screen | 2.3-Inch large color screen large font size display |
| supporting software | without |
| Total Weight | 100g |
| Complete-built unit size | 130*70*25mm |
| Minimum measurement surface | F11.5mm |
| Operating Environment | Temperature: 0 ℃ -60 ℃, Humidity: 20% RH - 90% RH, use in environment without strong magnetic field |
| Unit display | μm / Thousand |
| Shutdown method | Manual/Automatic |
| data storage | It can be stored in 10 groups, 200 in each group, and a total of 2000 data can be stored |
| Calibrated mode | Zero point calibrated, two point calibrated, multi point calibrated |
Packing list
Thickness gauge x1, calibrated diaphragm (50, 100, 250, 370 μm) x4, iron matrix x1, ABS instrument Encasement box x1, battery x1, manual x1, certificate x1, cleaning cloth x1
After-sales instructions
Warranty days: 365 days
【Attention】
1. The manufacturer promises to provide a one-year warranty period for the product for customers in Nanbeichao Mall
2. During the warranty period, the freight sent back and forth by the customer shall be borne by the customer
3. The damage caused by improper use by customers and the damage caused by the logistics process are not covered by the free warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/187/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
